KTDC-BV Series V Fold Coreless Garbage Poly Bag Making Machine

This Coreless Garbage Poly Bag Machine is designed to convert plastic films into coreless V-fold plastic bag rolls. Such as Plastic Garbage bags, Trash bags, and disposable bags. Each bag on the roll is individually folded and sealed. After a strong bottom sealing, the bags are cut by the perforation knife to ensure the bags can be torn off easily.

Features

  • With Double Servo Control System
  • With Length Control System
  • With Auto Counting System
  • With PLC Touch Screen Control System
  • With Auto Roll Bag Change System
CE Certification

Products Our Machine Can Make

Poly Bag Making Machine
Poly Bag Making Machine
Poly Bag Making Machine
Poly Bag Making Machine
Machine Specifications
Model KTDC-BV 700 KTDC-BV 900 KTDC-BV 1200
Raw Material HDPE, LDPE, Biodegradable Films, Recycle Materials
Finial Products V Fold Coreless Bag on Roll (Flat Bag)
Production Line 1 Line 1 Line 1 Line
Max. Raw Material Width 600mm 850mm 1100mm
Bag Making Height 300-1500 mm 300-1500 mm 300-1500 mm
Max. Finished Roll Width 350mm 450mm 550mm
Max. Finished Roll Diameter 120mm 120mm 120mm
Raw Material Thickness 7-35 micron/layer 7-35 micron/layer 7-35 micron/layer
Bag Making Speed 50-200 bags/min 50-160 bags/min 50-120 bags/min
Material Feeding Speed 80-100m/min 60-90m/min 50-80m/min
Air Compressor 3HP 3HP 4HP
Machine Power 12kw 13kw 14kw
Machine Weight 2800kg 3200kg 3800kg
Machine Size (LWH) 7000 x 2000 x 1900mm 7500 x 2000 x 2100mm 7500 x 2200 x 2400mm



Model KTDC-BV 450X2
Raw Material HDPE, LDPE, Biodegradable Films, Recycle Materials
Finial Products V Fold Coreless Bag on Roll
Production Line 2 Lines
Ma. Raw Material Width 400 mm
Bag Making Height 200-1000 mm
Max. Rewind Roll Width 200 mm
Max. Rewind Roll Diameter 150mm
Raw Material Thickness 7-25 Micron/Layer
Bag Making Speed (50-200 bags/min) x 2
Material Feeding Speed 80-100m/min
Air Compressor 5HP
Machine Power 15kw
Machine Weight 3500kg
Machine Size (LWH) 6000 x 2400 x 1900mm
